A6+ Two Way Car Alarm System With Remote Starter And 3d Sensor

Model:

A6+

Minimum:

Payment:

T/T； western union; PayPal

Origin:

Guangdong, China (Mainland)

Brand:

BATTLESNAKE

Inquiry

Write a Review

Type

TWO WAY CAR ALARM

Voltage

9V-36V

Car Make

Universal

Certification

CE, ROHS

Feature

Function Features
- Noiseless security mode
- Security mode with sound signals
- Light notification signals
- The hood is open
- The impact sensor has been actuated
- The doors locks are closed
- The remote control transceiver is turned on
- The door locks are open
- Calling from inside the car
- Confirmation of connection with the car
Energy saving model of the remote control
- The ignition is turned on

- The trunk is open

- Alarm clock model
- Post meridiem (PM)
- Ante meridem (AM)
- Mode of turn-off of the impact sensor
- Indication of time and temperature
- Temperature scale .
- Timer mode
- Battery control
- Channel 2 is turned on
- Channel 3 is turned on
- Working engine
- The doors are open
- Mode of notification by means of vibration
- Automatic restart mode

- Valet service mode is turned on

Specifications	Carrier frequency of radio control signal – 433.92 MHz
	Maximum working radius of main remote control – 600 m*
	Maximum working radius of pager – 1200 m*
	Maximum working radius of additional remote control – 15 m*
	Impact sensor type – piezoelectric
	Working temperature – from -40°C to +85°C
	Direct current voltage – 9-18 V
	Current, used by the car alarm system in the security mode – 20 mA
	Maximum output current: siren circuits – 2A side marker circuits – 2x7,5 A circuits for operating the electric actuators of door locks – 15A engine blocking circuit – 40 A circuits for additional operation channels – 300 mA
	Power supply of additional remote control – 3 V ( 1 CR2032 battery-
	Power supply of main remote control – 1.5 V (1 AAA battery-

A6+ Two Way Car Alarm System With Remote Starter And 3d Sensor 7

A6+ Two Way Car Alarm System With Remote Starter And 3d Sensor 8

A6+ Two Way Car Alarm System With Remote Starter And 3d Sensor 9

A6+ Two Way Car Alarm System With Remote Starter And 3d Sensor 10

A6+ Two Way Car Alarm System With Remote Starter And 3d Sensor 11

A6+ Two Way Car Alarm System With Remote Starter And 3d Sensor 12

A6+ Two Way Car Alarm System With Remote Starter And 3d Sensor 13

A6+ Two Way Car Alarm System With Remote Starter And 3d Sensor 14

A6+ Two Way Car Alarm System With Remote Starter And 3d Sensor 15

A6+ Two Way Car Alarm System With Remote Starter And 3d Sensor 16

A6+ Two Way Car Alarm System With Remote Starter And 3d Sensor 17
